High Speed Module Electronic Jacquard Loom For Jacquard Machine

    Buy cheap High Speed Module Electronic Jacquard Loom For Jacquard Machine from wholesalers

    Buy cheap High Speed Module Electronic Jacquard Loom For Jacquard Machine from wholesalers
    • Buy cheap High Speed Module Electronic Jacquard Loom For Jacquard Machine from wholesalers
    • Buy cheap High Speed Module Electronic Jacquard Loom For Jacquard Machine from wholesalers

    High Speed Module Electronic Jacquard Loom For Jacquard Machine

    Ask Lasest Price
    Brand Name : GOODFORE
    Model Number : 5376 hooks
    Certification : ISO
    Price : CN¥31,679~CN¥63,363/set
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 200/set per month
    Delivery Time : 1-3 working days
    • Product Details
    • Company Profile

    High Speed Module Electronic Jacquard Loom For Jacquard Machine

    High speed electronic Jacquard head :


    Quick Details
    Condition:
    New
    Warranty:
    1.5 years, 1year
    Applicable Industries:
    jacquard loom
    Weight (KG):
    1200
    Video outgoing-inspection:
    Provided
    Machinery Test Report:
    Provided
    Marketing Type:
    Hot Product 2019
    Place of Origin:
    China
    Brand Name:
    GOODFORE
    Use:
    loom jacquard
    Type:
    electronic loom jacquard
    Material:
    Steel and plastic
    Color:
    White
    Quality:
    High Level
    Model:
    WGT24 electronic loom jacquard
    Service:
    Video technical support
    MOQ:
    1 Piece
    Brand:
    GOODFORE
    Keyword:
    loom jacquard
    Name:
    loom jacquard

    Supply Ability
    Supply Ability
    1000 Set/Sets per Month

    Packaging & Delivery
    Packaging Details
    Wooden case
    Port
    SHANGHAI
    Picture Example:
    Lead Time:
    Quantity(Pieces)1 - 12 - 10>10
    Est. Time(days)2050To be negotiated
    name
    jacquard machine
    place of production
    made in china
    warranty
    one year
    quality
    high quality
    model
    jacquard machine
    Jacquard needle numer
    1408 2688 3200 4096 5120 (16A type)
    5376 6912 7680 (24A type )
    8912 9216 10240 12288 20480 (32A type )
    Suitable machine type
    high speed rapier loom ,air-jet ,water -jet ,gripper loom
    Opening height
    20-120mm
    Pattern input
    USB/network transmission
    Transmission type
    all oil bath gear
    Connection method
    vertical shaft /motor drive inderpendtly
    The highest speed
    650rpm
    Technical feature
    patent technology wallboard oil -bath gear transmission ,stable and reliable, suitable for large needle number machine


    products picture



    Product application


    High Speed Module Electronic Jacquard Loom For Jacquard MachineHigh Speed Module Electronic Jacquard Loom For Jacquard MachineHigh Speed Module Electronic Jacquard Loom For Jacquard Machine


    Operating procedures:

    1. During maintenance, the left and right red stop buttons must be pressed first, indicating that the machine is in the process of maintenance.

    2. It is strictly forbidden to cross the barrier. Go up and down the stairs slowly and carefully. Be careful of sliding.

    3. It is strictly prohibited to remove the cross bar of the corrugated plate crossing the bridge, hang it on the ground of the gantry arbitrarily and roll down, injuring the equipment and the car stopper.

    4. The tools shall not be placed at will to prevent accidents caused by falling out of hand during operation.

    5. When the safety baffle is moved due to maintenance needs, it shall be restored and returned in time after maintenance.

    6. When the machine is started after maintenance, it shall be operated at a slow speed for more than 2 weft, and the fast train can be operated only after it is confirmed that the cloth quality is normal and the equipment operates normally.


    Our service

    • Provide technical design and solutions;
    • Design and manufacture non-standard equipment;
    • Carry out professional technical training and guidance according to the contract;
    • Spare parts are available at any time;
    • Remote technical consultation and service;
    • Provide other special technical services according to customer requirements.
