    GA628 High Speed Sectional Warping Machine 600m/Min 18KW

    Ask Lasest Price
    Brand Name : GOODFORE
    Model Number : GA628
    Certification : ISO
    Price :
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 100 sets/month
    Delivery Time : 20 working days
    • Product Details
    • Company Profile

    GA628 High Speed Sectional Warping Machine 600m/Min 18KW

    GA628 High Speed Sectional Warping Machine High Speed Machine Textile Machines


    Quick Details
    Applicable Industries:
    Garment Shops, Manufacturing Plant
    Showroom Location:
    None
    Video outgoing-inspection:
    Provided
    Machinery Test Report:
    Provided
    Marketing Type:
    New Product 2022
    Warranty of core components:
    1 Year
    Core Components:
    PLC, Engine, Gearbox, Motor
    Condition:
    New
    Type:
    sectional warping and beaming machine
    Application:
    weaving
    Production Capacity:
    600m/min
    Place of Origin:
    Jiangsu, China
    Brand Name:
    goodfore
    Dimension(L*W*H):
    2.8*5.6*3.5m
    Weight:
    6500 KG
    Power:
    18K
    Warranty:
    1 Year
    Key Selling Points:
    Automatic
    Reed width:
    280
    Machine type:
    Water Jet Power Loom
    Motor capacity:
    18KW
    Function:
    Textile Warping Machine
    Keywords:
    Multifunctional
    Color:
    blue or customize

    beam speed100m/min
    warping speed600m/min
    Working width2300-5500mm
    Beam flange dia.≤φ1000mm
    Brake distance≤3m( when speed is 100m/min)
    Cone length1320


    Product photos

    GA628 High Speed Sectional Warping Machine 600m/Min 18KW


    Our Advantages

    1. Axial displacement of warping table is control by accurate servo motor. Start point and section location can be set
    automatically.
    2. Space reed and section are kept in equidistance which is optional .
    3. Warping brake is clamp type. Beaming brake is external steel strip damping type, which eliminates the noise and uneven tension
    problems occured in traditional.
    4. It is equipped with microcomputer and PLC, with function of total length count, roll lenth count, section count, broken end
    memory and stop motion of full total length or warp, etc.
    5. Touch screen shows info clearly, easy to operate.
    6. Section tension is constant during warping and beaming.
    7. Steel cone with angle 1:6.3 is good for kinds of warping.
    8. Wax and pressure device are optional for beaming machine.
    9. Creel number and pitch are as your requirements
    10. Warp stop motion and static eliminator are optional.

    Our service

    1. We provide process design and verification free of charge.

    2. Provide other special technical services according to customer requirements.

    3. Arrange special personnel to track all orders and inform customers in time.

    4. We provide free technical services on textile machinery and applications.

    5. Equipped with perfect sales network.


    Recommend Products


    Factory

    FAQ

    1.Q: When we receive your machine ,is there any other accessories we will get?

    A: Yes,some easy abrasion spare parts will be provided free in case when some small problems happen.

    2..Q: What about the after-sale service?

    A: We provide 12 months quality warranty after dispatch,and some free easy abrasion spares of machine,we also provide long time free technical advisory services and technical clonsluting services,we will dispatch our engineer to provide online technical service if it is necessary.

    3. Q: How does your factory do regarding quality control?

    A: Quality is priority. Staff always attach great importance to quality control from the very beginning to the end of the production. Every product will be fully assembled and carefully tested before it's packed for shipment.

    4.Q:What are your terms of payment?
    A: D/A, L/C, D/P, T/T, Western Union.
    5.Q:What about the transportation?
    A: Usually we take seaway,cause it's more convenient and cheaper.
