GA528 Polyester Sectional High Speed Warping Machine 18KW

    Buy cheap GA528 Polyester Sectional High Speed Warping Machine 18KW from wholesalers

    Buy cheap GA528 Polyester Sectional High Speed Warping Machine 18KW from wholesalers
    • Buy cheap GA528 Polyester Sectional High Speed Warping Machine 18KW from wholesalers
    • Buy cheap GA528 Polyester Sectional High Speed Warping Machine 18KW from wholesalers
    • Buy cheap GA528 Polyester Sectional High Speed Warping Machine 18KW from wholesalers
    • Buy cheap GA528 Polyester Sectional High Speed Warping Machine 18KW from wholesalers

    GA528 Polyester Sectional High Speed Warping Machine 18KW

    Ask Lasest Price
    Brand Name : GOODFORE
    Model Number : GA528
    Certification : ISO
    Price :
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 100 sets/month
    Delivery Time : 20 working days
    • Product Details
    • Company Profile

    GA528 Polyester Sectional High Speed Warping Machine 18KW

    GA528 High Speed Sectional Warping Machine


    Quick Details
    Applicable Industries:
    Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Home Use, Printing Shops, Advertising Company
    Showroom Location:
    None
    Video outgoing-inspection:
    Provided
    Machinery Test Report:
    Provided
    Marketing Type:
    Ordinary Product
    Warranty of core components:
    1 Year
    Core Components:
    PLC, Engine, Gearbox, Motor
    Place of Origin:
    Jiangsu, China
    Brand Name:
    goodfore
    Machine Type:
    warping machine
    Product:
    Yarn
    Material Capabilities:
    Yarn
    Condition:
    New
    Warranty:
    1 Year
    After-sales Service Provided:
    Engineers available to service machinery overseas, Free spare parts, Video technical support, Online support
    Working width:
    2300MM
    Power:
    18KW
    Raw material:
    Polyester
    Type:
    Warp Typing Machine
    After Warranty Service:
    Video technical support, Online support
    Local Service Location:
    None
    Certification:
    ISO

    Main Technical Data

    Work width

    2300-3600(mm)

    Particular specification can be customized according to requirements

    Beam flange diameter≤ 800(mm)
    Warping speed0-400(m/min)
    Beaming speed0-80(m/min)
    Deviation of linear speed±2%(with a speed of 300m/min)
    Braking distance 3m(when speed is 500m/min)
    Drum diameter800
    Cone length1310
    Cone angle

    9° (1:6.3)

    Stripe traverse speed0.001-9.999(mm/r)(No grade)
    Deviation of stripe traverse0.2%
    Positioning accuracyAdjustable
    Go and roller distanceAutomatic
    Stripe locationAutomatic
    Setting range

    0.1-999.9(min)

    (Shall not be greater than the length of the yarn guide rod)

    Creel spindle pitch

    300*250(mm)(wool,cotton)

    290*290(mm),220*220(mm) (synthetic,filament)

    Creel spindle number392(wool,cotton) 480(synthetic,filament)
    Input power3*380V±10%
    Capacity30KVA
    Warping motor7.5Kw
    Beaming motor11Kw
    Section traverse servo1.5Kw
    Main machine weight5000KG
    Creel weight2500KG

    GA528 Polyester Sectional High Speed Warping Machine 18KWGA528 Polyester Sectional High Speed Warping Machine 18KWGA528 Polyester Sectional High Speed Warping Machine 18KWGA528 Polyester Sectional High Speed Warping Machine 18KW


    Our Advantages

    1. Our belief is to pay attention to every detail.

    2. Our motivation is the smile of customer satisfaction.

    3. We have the original factory to ensure the best quality control of all kinds of export machinery.

    4. Stable quality: Depending on the needs of the user, Our company has been through professional quality system certification. please feel free to purchase.

    5. Continuous research and development of new products: in order to explore the international market, our company will achieve two breakthroughs: networking and service. Jacquard machine, trademark machine and carpet machine parts enter the foreign market. And improve the quality of production to meet the higher requirements of customers.

    6. Integrity management: Our company has established a long-term stable cooperative relationship with a number of manufacturers. Our customers are across both at home and abroad.

    7. Small profits: Our company's strength, re-credit, keep the contract, to ensure product quality, has won the trust of customers under the principles of various categories and low price.Welcome old and new customers from home and abroad call or come to our company for consultations and negotiations.Consecutive sales increasement of 10 years.

    8. Best Service: Customer's satisfaction is always Goodfore Tex machinery priority concern, we are keen to solve any problem. We will answer all questions asked, help everyone in need and give response to every prayer.

    Our service

    1. Timely response through email, phone call, fax or any instant messaging.

    2. Timely supply the production designs.

    3. Timely communication on the technical proposal.

    4. Timely sending pictures of the goods ready to be shipped.

    5. Timely delivery and high quality.

    6. The best solution for individual case.


    Recommend Products

    Our Factory


    FAQ

    1.Q: When we receive your machine ,is there any other Accessories we will get?

    A: Yes,some easy abrasion spare parts will be provided free in case when some small problems happen.

    2..Q: What about the after-sale service?

    A: We provide 12 months quality warranty after dispatch,and some free easy abrasion spares of machine,we also provide long time free technical advisory services and technical clonsluting services,we will dispatch our engineer to provide online technical service if it is necessary.

    3. Q: How does your factory do regarding quality control?

    A: Quality is priority. Staff always attach great importance to quality control from the very beginning to the end of the production. Every product will be fully assembled and carefully tested before it's packed for shipment.

    4.Q:What are your terms of payment?
    A: D/A, L/C, D/P, T/T, Western Union.
    5.Q:What about the transportation?
    A: Usually we take seaway,cause it's more convenient and cheaper.
